Cabin

Air suspension MAN F3000 cab, sleeper, hydraulic shock absorb adjustable seat, safety belt,

              adjustable steering, sunroof, sun cap, bumper

Engine

Diesel, 4-stoke Direct injection, 6-cylinder in line, radiator, Turbo-charging.

Model:

WP12NG380E40

WEICHAI engine with European WEVB technology

Engine power

380HP/279kw

Displacement(L):

11.596 Liter

Max torque:

1750NM@1300~1600

Gear box

Applied American FULLER technology

Model:

FAST 9JS150A

Speed:

9speed, 1reverse

Axle(front/rear)-Military axle

Front axle

7.5ton MAN technology non-driving steering axle

Tandem

13T STR technology double reduction, hub redactor driving axle

(Driving axle)

Wheel differential locks

Clutch

D430 diaphragm type, single dry frictional disc, hydraulic boosting.

Brake

Service brake: Double circuit pneumatic brake

Parking brake: Spring-Power drum brake

Engine brake: Engine exhaust brake(EVB)

Steering

ZF technology, driver sit at theleft hand side

Electric  Equipment

Operating voltage:

24Vnegative grounded

Starter:

24V,5.4KW

Alternator

28V,758W

Battery voltage

12V/135Ah,cigar lighter

Frame

850mm (width)-Variable sections strengthened frame, made as tough road condition

Tyre

10+1 spare tyre with wheel

12.00-20 nylon tire

Suspension system:  Leaf spring type

Front/Rear

10/12

Overall dimension(mm): 7475x2490x4000(Length x width x height)

Wheelbase

3800+1350mm

Track:

Front/Rear

2036/1800/1800

Approach/Departure angle

18/65

Front /Rear overhang

1525/800

Max speed

84km/h

Curb weight:

9750kg

LNG tank volume

450L
