Axle load distribution (kg)

Front

4879

Width (mm)

2500

Rear

4338

Height mm

2890

Curb weight (kg)

--

Wheel Base(mm)

3825+1350

Axle Load distribution(kg)

Front

--

Wheel Track(mm)

Front

2020

Rear

--

Rear

1880

GVW (kg)

25000

Min. Ground Clearance(under rear axle) (mm)

314

Axle Load distribution (kg)

Front

7000

Approach Angle (°)

25

Rear

18000

Departure Angle(°)

58

Max. drawing Capacity (kg)

Front Overhang (mm)

1493

Total weight with trailer (kg)

Rear Overhang (mm)

850

Max. Load Capacity(kg)

Distance from tractor seat to floor

Performances

Min. Steering Diameter (m)

18

Tractor seat pin D.

Max. Speed (km/h)

73

Engine

Model

WP10_340E32

Max. Grade ability (%)

35.76

Displacement(L)

9.726

Parking Brake Grade Angle (%)

Max. Output Power kw/rpm

250 /2200

Direct Shift Min. Stable Speed(km/h)

Max. Torque Nm/(r/min)

1350/1200-1600

Direct Shift Accelerate Time (s)

(20-70km/h)

Rated fuel consumption g/kw·h

Sliding Distance(from 50km/h) (m)

Min. Fuel Consumption g/kw·h

210

Braking Distance(from 30km/h) (m)

Cab

Type

Cab on engine, all metal closed, integral front tilting angle 44º

Fuel Consumption(l/100km)

≤36

Fuel Tank Capacity (L)

400

Seats

2

Frame

Type

Side rails, punching and riveted construction

Clutch

Type

Dry type, single plate, diaphragm spring clutch, hydraulic controlled and air auxiliary power supply

Main Rail section

320×90×(8+8)

Auxiliary Rail Section

Driven Plate Dia.

φ430(mm)

Transmission

Model

FAST RTD-11509C

Power Steering

Model

Recycle ball type, Hydraulic power steering

Forward Shifts Ratio

12.42, 8.26, 6.08, 4.53, 3.36, 2.47, 1.81, 1.35, 1.0,

Ratio

23

Pump Max. pressure(kPa)

15000

Reverse Shift Ratio

12.99

Wheel Alignments

Wheel Camber

1°

Brake System

Rated working air pressure (kPa)

784

kingpin sidewise inclination

3°

Driving Brake

Dual circuit, air pressure brake

Kingpin extroversion

2°

Parking Brake

Spring energy storage type

Toein(measured onΦ648 diameter)

0-2(mm)

Auxiliary Brake

Exhaust Brake

Rear Axle

Type

300 double reduction

Electrical System

Type

Single line, negative grounded

Reduction Ratio

5.921

Voltage

24V

Generator

2000W

Differential lock

wheel differential lock

Battery(V/Ah)

2-12/150

Truck Body

Measurement(mm)

Size: 5800x2300x1500

Thickness of steel: bottom 8mm side 6mm

Tipping system: middle tipping with T tipping system

Wheel

Rim

9.00×22.5

Tyre

Model

12R22.5-16

Air pressure(kPa)
