SHACMAN WEICHAI Diesel Manual 8x4 Tipper Truck
No.: Jim-09
Vehicle Type: Dump Truck
Brand Name: SHACMAN
Person in charge: Jim yao
Cel: 0086 176 6971 7509
Whatsapp: 8617669717509
E-mail: sales29@chinatruck.cc
FREE GET QUOTE
Details
SHACMAN WEICHAI Diesel Manual 8x4 Tipper Truck
Model | SX3314DR366 | |
Traction type | LHD | |
Drive System | 8x4 | |
Cabin | F2000 Flat Cabin, one sleeper, Air Conditioner | |
Engine | Brand | WEICHAI |
Model | WP10.380E32 EURII | |
Rated power | 380hp | |
Engine displacement | 9.726 liters | |
Gearbox | FAST 9 Speeds (RTD-11509C) | |
Clutch | Ф430 Diaphragm type | |
Steering | ZF technology | |
Axle | Front | 6.5 Ton STR |
Rear | 16 Ton STR double reduction axle, ratio:5.73 | |
Max. running speed (km/h) | 77 | |
Tire | 12.00R20 radial tire(12+1) | |
Fuel tank | ||
Kerb weight (kg) | 14500 | |
Total mass (kg) | 31000 | |
Wheel base (mm) | 1800+3600+1350 | |
Overhang (mm) (front/rear) | 1525/2054 | |
Track (mm) (front/rear) | 1939/1850 | |
Approach / departure angle(°) | 20/28 | |
Dimensions（L*W*H）(mm) | Overall | 10500x2500x3500 |
Dump body | 7600x2300x1700( | |
Thickness (mm) | Bottom 8 , side 6 | |
Hydraulic lifting system | Front lifting | |
