Lifting Structure

Lifting weight

kg

7500

Max. Lifting weight

kg

12435

Max. Lifting weight of original place

g

14000

Max. Lifting weight of full extension boom

kg

4000

Rated towing weight

kg

32000

Max. Designed towing weight

kg

60000

Effective length of boom

mm

3415

Extension traveling of boom

mm

1700

Folding angle of boom

°

90

Under lift Structure

Max. Rated hanging weight

kg

14000

The height from hook to the ground

mm

9430

Extension traveling of lifting boom

mm

3045

Turning angle

°

360

Numbers of winch

piece

2

Rated pulling power of winch

kg

10000×2

Dia. Of steel cable

mm

18

Length of steel cable

m

40

Min. Speed of steel cable

m/min

7

Rotation angle

°

54

Vehicle

Parameters

External dimension

mm

10410×2500×3500

Chassis model

ZZ1257M5847C

Drive

6×4

Axle base

mm

5825+1350

The whole weight of empty load

kg

19435

Load of front axle of empty load

kg

7205

Load of rear axle of empty load

kg

12230

The whole weight of full load

kg

32000

Load of front axle of full load

kg

7000

Load of rear axle of full load

kg

25000

Wheel base (front/rear axle)

mm

2022/1830

Front suspension

mm

1500

Rear suspension

mm

1205

Approach angle

º

16

Departure angle

º

23

Min. Ground clearance

mm

260

Min. Turning diameter

m

≤24

Grade ability

%

≥30

Max. Speed

km/h

90

Engine model

-

WD615.93E

Engine emission

L

9.726

Rated power

kw/r/min

213/2200

Max. Torque

n·m/r/min

1160/1100～1600

Fuel type

Diesel

Tire size

12.00-20

Persons

2
