Chassis: BENZ chassis

Cabin Features: Benz, long cabin, flat roof, one sleeper,A/C

Engine brand: WEICHAI

Model: WP10.336  EURIII Common Rail

Engine output: 336hp @2200 rpm

 Bore/Stroke(mm):126/130

  Displacement: 9.726L

Torque: 1200-1600r/min

Transmission (gear box): 9T-160  fuller gear box

Clutch: D430 Diaphragm type

Steering: ZF8098

Front axle: BENZ front axle(7.5ton)

Rear axle: BENZ strengthened axle (punching-welding axle housing, double

        Reduction driving axle, inter-wheel differential and differential lock)   Ratio: 5.263

Spring: 10/13                                            Fuel tank: 300L

Tire: 12.00-20                                          No.tyre: 10+1 spare

Kerb mass: 12870kg                                     Total mass: 25000kg

Approach angle(°): 30                                     Departure angle(°): 23

Front overhang(mm): 1515                                 Rear overhang(mm): 1410/2530,1410/2340

Front/rear track(mm): 1995;1872/1872                      Max.speed(km/h) : 93

Wheel base(mm): 3450+1450                              Dimension(mm): 8650*2500*3820
