Brand New Shacman F3000 Cement Mixer Truck 6x4 340HP 10m3 Cement Mixer Truck For Sale
No.: Xeno_35
Vehicle Type: Concrete Mixer Truck
Brand Name: SHACMAN
Person in charge: Marc Zhou
Cel: 8617664086916
Whatsapp: 8617664086916
E-mail: sales3@chinatruk.cc
FREE GET QUOTE![_20230914234530](res/en/20230914/90bbf1de4ed976d9.jpg)
Details
Main Technology Parameter | |
Model name | Shacman Delong F3000 Cement Mixertank Truck |
Model | SX5255GJBHR384 |
Driving type | Left hand drive |
Traction type | 6×4 |
Color | optional |
Weights | |
Rated payload weight(kg) | 20000 |
Curb weight(kg) | Approx.13000 |
Dimensions | |
Wheelbase(mm) | 3775+1400 |
Overall dimension(mm) | Approx.9380×2490×3900 |
Cement capacity(m3) | 10 |
Engine | |
Engine model | WP10.340E22+PTO, 340HP |
Emission standard | Euro 2 |
Engine type | 4 stroke water-cooled, inter-cooling |
No. of cylinders | straight-6 cylinders |
Displacement(L) | 9.7L |
Max. output (kw) | 250kw |
Fuel Tanker(L) | 300 aluminum fuel tank |
Drive Line | |
Transmission | 10JSD180 |
10 speeds ,10 forwards,2 reverse gear, manual operation | |
Steering | Power steering |
Brake | air brake, engine exhaust brake |
Cab | |
Cabin | Extended flat top cab; Single sleeper, with A/C |
Standard configuration | Air container |
Axle | |
Front axle | MAN 9.5T |
Rear axle | MAN 16T , double reduction driving axles with inter-wheel & inter-axle differential locks; Speed ratio 5.92 |
Tire | |
Tire specification | 12.00R20 standard tire,10 tires+1 spare part |
Parameter | |
Economic speed/maximum speed (km/h) | 45~60/85 |
Max. Gradeability | 35(%) |
Rear overhang(mm) | 1550 |
Frame(mm) | 850×300(8+7) |
Suspension | Front and rear multi leaf springs(9/12) |
Tank body parameters | |
Tank volume | 10m3 |
Water tank capacity | 500L |
Tank length | 5100mm |
Tank material thickness | 5mm |
Tank material | Steel |
Color | Customized |
