Specification

Size13,000*3000*1,250mm, optional

Body SheetFloor thickness: 4mm, checkered plate;

Body material: high tensile steel.

ChassisHeavy duty and extra durability designed I beam

Axle3*16 tons axles (fuwa, bpw, optional )

Tire315/80R22.5 tubless tires, 13 pcs (12R22.5, 11.00R20, 12.00R20.etc model is optional)

Rim9.0-22.5

SuspensionHeavy duty mechanical suspension with spring leaf

Braking system2 line air braking system with air tank, WABCO emergency relay valve, braking chambers and mechanical slack adjusters.

Electrical system24V, LED lights. 7 pin electrical connector. Parking, stop, reverse, number plate and indicator lights conform to European standard, rear front and side reflectors.

Shot blastingChassis is comletely shotblasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.total 80-100 microns. high quality painting. the whole trailer waxed.

Landing gearJOST brand landing gear

King pin(2') 50# or (3.5') 90#

RampMechanical or Hydraulic system

Tool box1 pcs of tool box
