Parameter in work conditions

output in theory

m3/h

125

index of the pump carry capacity

Mpa.m3/h

586

theoretic pumping pressure

Mpa

8.5

bucket volume

L

700

height of top surface of bucket

mm

1400

model of distribution valve

S pipe valve

max operation radius

m

54.9

max operation height

m

59.9

max operation depth

m

41.5

diameter of delivery pipe

mm

125

length of rear hose pipe

m

3

rotary range of aggregate carrying pipe

±270 º

quantity of boom

5

rotary angle of each boom

°

90/180/180/230/180/270

remote control distance

m

200

parameter during running

max speed

km/h

80

min turning radius

mm

12500

brake distance

m

10

approach angle

°

16

departure angle

°

11

chassis model

HOWO

ZZ5437S5067C1

CNHTC's engine

wheel base between the first and second axle

mm

1800

wheel base between the second and third axle

mm

5000

wheel base between the third and fourth axle

mm

1350

front tread

mm

2022

rear tread

mm

1830

max engine output

kw

275(2200r/min)

max engine torque

n.m

1500 /(1100~1600 r/min)

max gradient ability

%

37

consumption

L/100km

40

out dimension(length×width×height)

mm

14500mm×2500×4000

total weight

kg

46000
