FAW 20-30 ton dump truck for sale
No.: KOBE-210621
Vehicle Type: Dump Truck
Brand Name: FAW
Person in charge: Kobe Zhang
Cel: 0086 176 6971 7516
Whatsapp: 8618562629532
E-mail: sales30@chinatruck.cc
FREE GET QUOTE
Details
FAW 20-30 ton dump truck for sale
1.WEICHAI 340,380HP
2.EATON clutch
3.America parts
4.EATON/ FULLER gearbox
5.Front lift or middle lift
6.Steel Cabin for comfortable drive
7.WABCO valve
8.USA TRW steering
9. NORGREN solenoid valves
10.KOREAN GLOBAL free-maintenance battery
11.American TFLOCK self-locking nuts
12.American WOODWARD speed governor
13.GEMAN VOITH retarder
14.American TUTHILL cable
15.CVG American driver seat
16.American TENNECO shocker
17.AMP plug connector
Q: What’s the brand of your truck?
A: Our brand is FAW, First Automobile Works is the biggest truck manufacture in China, our products cover all series such as tractor truck, tipper truck, cargo truck, and other special trucks.
Q: How can we trust your company?
A: We are the official authority company by FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us. We are your reliable partner.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
Product Description
FAW 380HP,340HP, 20-30T, Dump truck, tipper truck
Packaging & Shipping
packing usually in nude,shipping by RORO or bulk carrier ship, also we can do CKD or SKD
Our Services
Warranty, technical training, spare parts surpplying ,Phone or mail support
Company Information
The first automobile anufacturer,has a history more than 45years, business expanded to asia,africa,south america and all over the world,More than 10000 units producing capacity, ISO 9001,TS16949,ISO14001,OHSMS18001 certificate
FAQ
FOB or CIF terms, T/T or L/C, small order is accepted
Optional:silicon oil fan, driving recorder, right hand driving,
Pto is included in tipper chassis.
Cargo body:
Volume range: 15-20m3
Thickness bottom 10 mm, side 6 mm(can be increased)
Hydraulic lifting system with f type, t type and front lift type(hiva brand is optional).
LOADING CAPACITY:20T/25T/30T
| Engine | STEYR tech, WEICHAI POWER 340hp,380hp |
| Gearbox | RT11509C/12JS160T |
| Tyre | 12R22.5/ 12.00R20 radial tyre |
| Cargo body size | 5400/5600x2300x1500mm |
| Lifting system | front lifting |
TRUCK SPECS | Overall dimension: | 8345x2496x3450mm | |
| Cabin | Cabin size: | standard cabin(2 seats)/ long cabin(2 seats and 1 bed)/ | |
| Air conditioner: | standard | ||
| Engine | Horsepower(hp): | 340 360 380 | |
| Tech: | steyr tech,WD615 | ||
| Engine Type: | 6-cylinder in line, 4-stroke, water-cooled,turbocharged, intercooled | ||
| Steering: | USA TRW | ||
| Emission Standard: | EUR 2,3,4 | ||
| Fuel Type: | Diesel | ||
| Max Torque: | 1500N.m | ||
| Engine Capacity(ml): | 9726 | ||
| Gear Box/Transmission | 9/12 speeds and 2 reverse speeds | ||
| steering: | TRW hyraulic steering with power assistance | ||
| Clutch | EATON Φ430 | ||
| Axles | Front Axles: | 9T | |
| Driving Axles: | 2x16T | ||
| Tyre: | 12R22.5,10 Tubeless tires with one spare tire/ 12.00R20,10 Radial tires with one spare tire | ||
| Max speed: | 75/80/85km/h | ||
| Tare weight(MT): | 12MT | ||
BODY SPECS | Body Dimensions (LengthXWidthXHeight): | 5600x2300x1500mm/ 5400x2300x1500mm | |
| Body steel (mm): | Q235 | floor 8mm(0.32in),side 6mm(0.24in) | |
| Cpacibility(M3): | 15CBM 20CBM | ||
| Lift System: | Middle hydraulic system with power assistance/ Front hydraulic system with power assistance | ||
| Wheel base: | 3825+1350mm | ||
| Track Width(front/rear): | 2041/1830mm(7.91x6ft) | ||
| Overhang(front/rear): | 1500/1870mm(7.55x6.14ft) | ||
| Approach/Departure Angle: | 19°/23° | ||
