Model name

FAW JH6 Tractor   truck

Model

CA4253P26K2T1YA80

Driving type

LHD

Traction type

6X4

Color

Optional

Weights

Gross Vehicle Weight(kg)

Approx.7000

Dimensions

Wheelbase(mm)

3300+1350mm

Overall dimension(mm)

Approx. 6945×2550×3850

Engine

Engine model

Xichai CA6DM2-42

420HP

Emission standard

EuroⅡ

Engine type

4 stroke water-cooled, inter-cooling

No. of cylinders

straight-6 cylinders

Displacement(L)

11.05 / Diesel

Max. output (kw)

312

Fuel Tanker（L）

600L aluminum fuel tank

Drive   Line

Gearbox

FAST 12JSD200T

Manual

12 forwards, 2 reverse gear

Maximum input torque

2000N.m

Steering

Power steering

Brake

Air brake, engine exhaust brake

Clutch

Eaton 430 clutch

Cab

Cabin

JH6 raised floor flat roof fully floating cab (four-point   air suspension)

Standard configuration

Intelligent air conditioning

Cab four-point air suspension

Axle

Front axle

2055 front axle

Rear axle

300wheel axle reduction (with differential lock   between wheels)

axle ratio

4.805

Tire   specification

Tire specification

315/80R22.5-18PR level

10 tires+1 spare part

Parameter

Economic speed/maximum speed(km/h)

45～75/90

Max. Gradeability

45(%)

Saddle

JOSTФ50

Frame

300*80*(8+8)

Suspension

11/12

Frame(mm)

300×80×8

Other

Whole vehicle WABCO valve,   WABCO clutch booster, Camel brand battery, 150AH battery, electric doors and windows,   front longitudinal pattern/rear mixed pattern, 4U bolt, dual I-bar rear   balance suspension, water tank protection plate, long-term maintenance coarse   filter, with internal spline power take-off and control mechanism, and front   and rear light protection net
