Size (mm)

6300 x 2550 x 4000

Cab

TX high roof cabin with A/C

Tires

12R22.5, 6+1pcs

Axle

VGD71 front axle，MCX16ZG rear axle

Engine

Model

WP10.380E22, Weichai ,Euro2 , Diesel

Engine power

280KW (380HP) @ 2200rpm

Max torque

1600 N.m @ 1500-1800rpm

Air intake type

turbo-charge and inter-cool

Alignment of cylinders

6 cylinders in line

Fuel injection type

Direct injection

Compression ratio

17: 1

Bore * Stroke

126x130mm

Gearbox

HW19710 gearbox with HW70 power take-off, 10 forward speeds + 2 reverse speeds

Steering

BOSCH

Fuel tank

400L fuel tank

Suspension

Standard version with less front and more leaf springs at the rear (3/9+6)

Main beam

TGA Technology Frame

Other

ABS (4S/4M)
