SHACMAN X3000 6x4 Dump Truck

A robust and versatile dump truck designed for demanding construction, mining, and transportation tasks. The SHACMAN X3000 features a powerful engine with multiple horsepower options, a durable chassis, and a spacious cargo body. Built with advanced components and safety features, this truck is engineered to handle extreme conditions while ensuring reliability and efficiency.

Key Features:

✔ Model: SX32566T384
✔ Driving Type: LHD (RHD is optional)
✔ Cabin: HW76, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four-point support floating suspension + shock absorber.
✔ Engine Options: WP10., Euro 2, 340 HP, 380 HP, 400 HP, 430 HP
✔ Transmission: HW19710, 10F & 2R, with PTO
✔ Steering: ZF power steering, model ZF8118
✔ Front Axle: VGD95, 1x9500 KGS
✔ Rear Axle: HC16, 2x16000 KGS
✔ Propeller Shaft: Double universal joint propeller shaft with gear-shaped coupling flange
✔ Chassis: Front suspension with 10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers, and stabilizer; Rear suspension with 12 leaf semi-elliptic springs, bogie spring, and stabilizer
✔ Brake System: Parking brake (emergency brake) with spring energy and compressed air operating on front shaft and rear wheels; Auxiliary brake with engine exhaust brake
✔ Electrics: Starter (24 V, 5.4 Kw), Alternator (3-phase, 28 V, 1500 W), Batteries (2 x 12 V, 165 Ah)
✔ Tyres: 12.00R20 radial tyres with one spare tyre
✔ Fuel Tank: 300L
✔ Cargo Body: 5400x2300x1500 mm, 18 CBM, Floor 8mm, Side 6mm
✔ Overall Dimension: 8250x2550x3450mm
✔ Color Options: White, black, red, yellow, green, blue

SHACMAN X3000 6x4 Dump Truck

SHACMAN X3000 6x4 Dump Truck

Specifications Reference:

• Model: SX32566T384

• Driving Type: LHD (RHD is optional)

• Cabin: HW76, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four-point support floating suspension + shock absorber.

• Engine:

• Model: WP10.

• Emission Standard: Euro 2

• Horsepower Options: 340 HP, 380 HP, 400 HP, 430 HP

• Transmission: HW19710, 10F & 2R, with PTO

• Steering: ZF power steering, model ZF8118

• Front Axle: VGD95, 1x9500 KGS

• Rear Axle: HC16, 2x16000 KGS

• Propeller Shaft: Double universal joint propeller shaft with gear-shaped coupling flange

• Chassis:

• Front Suspension: 10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers, and stabilizer

• Rear Suspension: 12 leaf semi-elliptic springs, bogie spring, and stabilizer

• Brake System:

• Parking Brake (Emergency Brake): Spring energy, compressed air operating on front shaft and rear wheels

• Auxiliary Brake: Engine exhaust brake

• Electrics:

• Starter: 24 V, 5.4 Kw

• Alternator: 3-phase, 28 V, 1500 W

• Batteries: 2 x 12 V, 165 Ah

• Tyres: 12.00R20 radial tyres with one spare tyre

• Fuel Tank: 300L

• Cargo Body:

• Dimensions: 5400x2300x1500 mm

• Capacity: 18 CBM

• Material Thickness: Floor 8mm, Side 6mm

• Overall Dimension: 8250x2550x3450mm

• Color Options: White, black, red, yellow, green, blue

Applications:

• Construction site transportation

• Mining operations

• Heavy cargo hauling

• Infrastructure projects
