Model name

SINOTRUK SITRAK C9H TRACTOR TRUCK

Driving type

Left hand drive

Traction type

4×2

Scope of application

Transportation of industrial and daily   necessities

Color

Optional

Weights

Gross Vehicle Weight(kg)

Approx.6800

Gross Combination Weigh (kg)

40000

Dimensions

Wheelbase(mm)

3900

Overall dimension(mm)

Approx. 6500×2500×3900

Engine

Engine model

MC13H.51-61, 510HP

Emission standard

Euro 5

Engine type

4 stroke water-cooled, inter-cooling

No. of cylinders

straight-6 cylinders

Displacement(L)

13.02 / Diesel

Max. output (kw)

380

Fuel Tanker

1000L+360L dual fuel tank

Drive Line

Gearbox

ZF12TX2620 TD

12 speeds, 12 forwards, 2 reverse gear,

AMT geabox

Steering

Power steering, Bosch steering gear

Brake

Front axle disc brakes, dual rear axle drum brakes

With Retarder

Cab

Cabin

C9H-E cab luxury version, double sleeper, airbag seats

Can be tipped forwardly, with inner A/C

Standard configuration

Air container,

Equipped with air deflector and side air   deflector

Axle

Front axle

VPD71DS 7.0T- Disc Brake

Rear axle

MCY13JGS self-adjusting arm single rear axle (drum)with   inter-wheel & inter-axle differential locks

Double reduction pneumatic brake

Speed ratio

2.85

Tire specification

Tire specification

Front aluminum alloy wheels + rear lightweight   wheels

12R22.5 (Low rolling resistance)

6 tires+1 spare part

Parameter

Maximum   speed (km/h)

89

Max. Gradeability

35(%)

Front track   width

2022mm

Rear track   width

1816mm

Suspension

Front and rear few leaf springs (3/5)

Frame(mm)

TGA technology frame

Saddle

90# JOST saddle

Bumper

Low bumper (non-metallic)

Fender

Integral fender

Power System

220V-1000W inverter power supply

Safety   devices

ABS(4S/4M)+ESC

Dual warning system (LDW+FCW); PPC

Imaging   system

Four directional camera

Air intake   system

Road version intake system

Exhaust system

Standard version exhaust system

Auto Cruise   System

PPC   automatic cruise control

start mode

One   key start keyless entry
