Traction type: 6x4

Driving type: LHD

Cabin: North Benz long cabin, Flat roof, One sleeper,A/C, (spoiler,option)

Engine brand: Weichai

Engine model: WP12NG380E40/280  EURIV

Max. output: 380hp@2200rpm

Max torque: 1500NM@1400-1600rpm

Bore/Stroke(mm):126/155

 Displacement: 11.596L

Gear box: Fuller 12 speeds(12JS200T)

Steering: ZF8098

Front axles: Benz (7.5ton)

Rear axles: Benz double-reduction axle Ratio: 4.769

Tyre: 315/80R22.5

Spring: 13/13

Gas tank capacity (L): 8x150L

Max. speed (km/h): 101

Max. Gradability(%): 28

Kerb. mass: 9970 kg                Total mass: 25000kg

Front overhang (mm): 1410                  Rear overhang (mm): 825

Front track (mm): 1995                         Rear track (mm): 1800/1800

Approach angle: 26 degree                      Departure angle: 60 degree

Wheel base (mm): 3850+1450               Dimension (mm): 7535x2495x3180
